Transponder Coding software
Product description
The Transponder Coding (TC) software is an ASCII/hex editor that can be used to read and write the CIS data carrier or EKS Electronic-Key on the PC.
Overview
- Byte-wise editing of the data
- Storage of the data as ASCII or hex file on the PC

Use for the identification system CIS
- In conjunction with read/write stations with serial interface
- For CIS3, CIS3A data carriers with 16 bytes of read/write memory or CIS3A-Mini data carriers with 116 bytes of read/write memory
- Display of the programmed data on the data on the data carrier in the ASCII and hex view
Use for the Electronic-Key-System EKS
- In combination with the Electronic-Key adapter read/write with serial interface or USB interface
- For Electronic-Key with 116 bytes of read/write memory and 8 bytes of fixed-code memory (serial number)
- Display of the programmed Electronic-Key data in ASCII and hex view, as well as the serial number in hex view
System requirements
- Operating system: Microsoft Windows® XP / Server 2003 / Server 2008 32-bit / Server 2008 64-bit / Windows® 7 32-bit / 64-bit / Server 2008 R2
- Processor: from Pentium 2
- Available memory: min. 64 MB
- Network: network card and TCP/IP protocol installed
- Hard disk space for the installation: approx. 20 MB
- Interfaces: serial or USB (depending on version of the read/write device)
